Omschrijving
Type
Type A: Mounting with countersunk screw
Latch
Zinc die casting
plastic coated
black, RAL 9005, textured finish SW
silver, RAL 9006, textured finish SR
Indexing mechanism
Stainless Steel
Countersunk screw DIN 7991
Stainless Steel (A2)
Stop locks GN 720 may be used as stops and feature a high degree of stability.
The inside ball-spring latching mechanism has 4 latching positions at a distance of 90° each. Thanks to the bolt attachment using the countersunk screw, the latching position is freely selectable.
The bar is solid and may be machined, if required.
The countersunk screw is enclosed as part of the set.
Uitvoering
| Filters resetten | Filter: | ||||
Code |
Product omschrijving |
Aantal |
Prijs |
Bestel |
CAD |
|---|---|---|---|---|---|
| 109526655 | GN 720-45-M6-A-SR |
|
|||
| 109526660 | GN 720-45-M6-A-SW |
|
|||
| 109526665 | GN 720-65-M8-A-SR |
|
|||
| 109526670 | GN 720-65-M8-A-SW |
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
d2 |
l1 |
l3 |
Gewicht (g) |
d1 |
l4 |
d3 |
B |
Belast. F max in N |
r |
l2 |
|---|---|---|---|---|---|---|---|---|---|---|
| 19 | 12 | 8.5 | 59 | M 6 | 0.5 | 9 | 13 | 500 | 45 | 13 |
| 19 | 12 | 8.5 | 59 | M 6 | 0.5 | 9 | 13 | 500 | 45 | 13 |
| 25 | 14 | 10.5 | 131 | M 8 | 0.6 | 14 | 18 | 1000 | 65 | 16 |
| 25 | 14 | 10.5 | 131 | M 8 | 0.6 | 14 | 18 | 1000 | 65 | 16 |
