Omschrijving
Material
Glass-fibre reinforced polyamide based (PA) technopolymer, black colour, matte finish.
Standard executions
- TTA-A: zinc-plated steel M10 screw, nut and washer.
- TTA-SST: AISI 304 stainless steel M10 screw, nut and washer.
Features
Maximum tightening torque for screw assembly 35 Nm.
Uitvoering
| Filters resetten | Filter: | ||||
Code |
Product omschrijving |
Aantal |
Prijs |
Bestel |
CAD |
|---|---|---|---|---|---|
| 201005200 | TTA.48-A |
|
|||
| 201005210 | TTA.48-SST |
|
|||
|
|
|
|
|
Gewicht (g) |
D buis |
d buis (BSP/GAS) |
|---|---|---|
| 260 | 48.3 | 1"1/2 |
| 260 | 48.3 | 1"1/2 |
